1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

Product Categories
Fuan Zhongzhi Pump Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

Brand Name : ZOZHI

Model Number : MS90L-4

Certification : CE,ISO

Place of Origin : FUAN CHINA

MOQ : 1pc

Price : $80.00-$90.00

Payment Terms : L/C, T/T

Supply Ability : 10000pcs/month

Delivery Time : 25 working days after received your payment

Packaging Details : Packed in cartons,veneer case or wooden case.

Product Name : 3 Phase Induction Motor

Application : Drivng

Power : 1.5kw/2Hp

Pole : 4

Phase : Three phase

Housing : Aluminum

Insulation Class : B,F

Protection : IP44 / IP54

Rated voltage : 380V

Duty : S1(continuous)

Contact Now

3 Phase Ac Electric Motors 380V MS90L-4 1.5KW 1450RPM Aluminum Body Copper Wire

3 Phase Induction Motor

MS series motors are enclosed, fan-cooled (TEFC), three-phase squirrel cage induction motors. They are newly designed in conformity with the relevant requirements of IEC standards.

Ms series motors have outstanding performance, such as high efficiency, energy-saving, high starting torque, low noise, little vibration, reliable operation, easy maintenance, etc.

Ms series motors are widely used in many places where do not exist combustible, explosive, or corrosive gas, and without any special pumps, fans, mixers, transport machines, machines, equipment, etc.

*IEC standard
*Superior finish
*Externally ventilated
*Lightweight construction
*IP55 protection
*Choice of foot or flange mounting
*Class F insulation
*CE approval
Operating conditions
Ambient temperature: -15≤θ≤40
Above sea level: not exceed 1000m
Rated voltage: ±5%

Technical data

Model Power (V) (HZ) Current (A) Power Factor

Eff

(%)

 Speed (r/min)

Tstart/

Tn

Tmax/

Tn

Ist/

In
HP KW
MS561-2 0.12 0.09 380 50 0.3 0.76 60 2750 2.3 2.4 6
MS562-2 0.16 0.12 0.37 0.78 63 2750 2.3 2.4 6
MS631-2 0.25 0.18 0.53 0.75 69 2800 2.2 2.4 4.5
MS632-2 0.33 0.25 0.68 0.78 72 2800 2.2 2.4 4.5
MS711-2 0.5 0.37 0.98 0.8 73 2800 2.2 2.4 4.5
MS712-2 0.75 0.55 1.35 0.82 75 2800 2.2 2.4 4.5
MS801-2 1 0.75 1.75 0.85 76 2800 2.2 2.4 4.5
MS802-2 1.5 1.1 2.55 0.85 77 2800 2.2 2.4 4.5
MS90S-2 2 1.5 3.36 0.87 78 2800 2.2 2.4 4.5
MS90L-2 3 2.2 4.93 0.87 78 2800 2.2 2.4 5
MS100L-2 4 3 6.31 0.87 83 2880 2.3 2.4 7
MS112M-2 5.5 4 8.12 0.88 85 2890 2.3 2.4 7
MS132S1-2 7.5 5.5 11 0.88 86 2900 2.3 2.4 7
MS132S2-2 10 7.5 14.9 0.88 87 2900 2.3 2.4 7
MS160L-2 25 18.5 34.7 0.9 90 2930 2.3 2.4 7
MS561-4 0.08 0.06 0.27 0.68 50 1300 2.2 2.3 5.5
MS562-4 0.12 0.09 0.36 0.7 54 1300 2.2 2.3 5.5
MS631-4 0.16 0.12 0.48 0.63 60 1400 2.2 2.4 4.5
MS632-4 0.25 0.18 0.65 0.66 64 1400 2.2 2.4 4.5
MS711-4 0.33 0.25 0.83 0.68 67 1400 2.2 2.4 4.5
MS712-4 0.5 0.37 1.12 0.72 69 1400 2.2 2.4 4.5
MS801-4 0.75 0.55 1.56 0.73 73 1400 2.2 2.4 4.5
MS802-4 1 0.75 2.01 0.75 75 1400 2.2 2.4 4.5
MS90S-4 1.5 1.1 2.83 0.78 76 1400 2.3 2.4 5
MS90L-4 2 1.5 3.84 0.78 76 1400 2.2 2.4 5
MS100L1-4 3 2.2 4.2 0.75 75 1400 2.2 2.4 5
MS100L2-4 4 3 6.78 0.82 82 1410 2.3 2.4 7
MS112M-4 5.5 4 8.82 0.82 84 1435 2.3 2.4 7
MS132S-4 7.5 5.5 11.8 0.83 85.5 1445 2.3 2.4 7
MS132M-4 10 7.5 15.6 0.84 87 1445 2.3 2.4 7
MS711-6 0.24 0.18 0.74 0.66 56 900 2 2.2 5.5
MS712-6 0.33 0.25 0.95 0.68 59 900 2 2.2 5.5
MS801-6 0.5 0.37 1.3 0.7 62 900 2 2.2 5.5
MS802-6 0.75 0.55 1.79 0.72 65 900 2 2.2 5.5
MS90S-6 1 0.75 2.29 0.72 69 910 2.1 2.2 5.5
MS90L-6 1.5 1.1 3.18 0.73 72 910 2.1 2.2 5.5
MS100L-6 2 1.5 3.89 0.76 76 940 2.1 2.2 5.5
MS112M-6 3 2.2 5.57 0.76 79 940 2.2 2.3 6.5
MS132S-6 4 3 7.4 0.76 81 960 2.2 2.3 6.5
MS132M1-6 5.5 4 9.75 0.76 82 960 2.2 2.3 6.5
MS132M2-6 7.5 5.5 12.9 0.77 84 960 2.2 2.3 6.5

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

Reviews from the client:

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

Shipping:

after 25~30days, we will deliver the goods, for loose goods better packed by the pallet for avoiding destroy

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

​

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

1.5KW 1450RPM 3 Phase Ac Motor 380V MS90L-4 S1 Duty

INFORMATION

Motor bearing heating analysis

(1) improper bearing coordination leads to the breakdown of the motor bearing system quickly.

(2) currently causes ablation of bearing system components and heating of bearing parts, resulting in a severe failure of the bearing system.

(3) improper lubrication system leads to bearing heating due to poor lubrication

(4) bearing heating caused by motor temperature rise or operating environment temperature.
